Grandstream GXW-4104 Analog FXO Gateway
- Category:ALL PRODUCTS,Best selling products,Grandstream gateways,Intel: Revolutionizing Computing Technology,New products
Grandstream GXW-4104 Analog FXO Gateway
The Grandstream GXW-4104 series enables businesses of all sizes to create an easy-todeploy VoIP solution. This FXO gateway offers the ability to seamlessly connect multiple locations and all devices within an office to any hosted or on premise IP PBX network to make deployments as easy as possible. The GXW410x series includes 4/8 FXO ports, 2 10/100 Mbps ports and supports SIP video through the H.264 codec. Advanced telephony features, easy automated provisioning and superb voice quality allow the GXW410x series to be the ideal VoIP gateway for businesses.
- 4 ports
- 2 10/100 Mbps network ports
- Comprehensive codec support, caller ID, flexible dial plans and security protection
- Advanced security protection with SRTP
A SIP proxy server such as Asterisk or a SIP registrar server can be deployed with the GXW-4104 series. In this environment, the SIP server handles SIP registration and call control and the GXW-4104 processes media conversion between IP and PSTN calls. By design, the system supports the North American call progress tones and signaling standards on PSTN sides.
Telephone Interfaces
- 4RJ11 FXO ports
Network Interfaces
- 10M/100Mbps, dual RJ45 ports
LED indicators
- Power, Network and Line LEDs
Voice-over-Packet Capabilities
- G.168 compiant Echo Cancelation, Dynamic Jitter Buffer, Moderm detection & auto-switch G.711
PTSN Fail-over Life Line
- PTSN failover on power failure
Voice Compression
- G.711, G.723, G.726 (40/32/24/16), G.729A/B/E, G.728, iLBC
DHCP Client
- Yes, Switched Mode or PPPoE
Fax over IP
- T.38 compliant Group 3 Fax Relay up to 14.4kpbs & auto-switch to G.711 for Fax Pass-through
QoS
- Diffserve, TOS, 802.1P/Q VLAN tagging
IP Transport
- RTP/RTCP
DTMF Method
- flexible DTMF transmission method, user interface of in-audio, RFC2833, and/or SIP info
IP Signaling
- SIP (RFC 3261)
SIP Server Profiles & Accounts Per System
- Up to 2 distinct SIP server profiles per system and independent SIP account per port
Provisioning
- TFTP and HTTP
Media
- SRTP
Management
- Syslog support, HTTPS, telnet, remote mamangement using web browser
Power
- Output: 12VDC Input: 100-240VAC / 50-60Hz
Environmental
- Operational: 32-104°F or 0-40°C
- Storage: 14-140°F or -10-60°C
- Humidity: 10-90% Non-condensing
Dimensions (LxWxH)
- 230mm x 135mm x 35mm
Mounting
- Wall mount and desktop
Short & Long Haul
- REN3: Up to 150ft on 24AWG line
Caller ID
- Bellcore Type 1&2, ETSI, BT, NTT, and DTMF-based CID
Polarity Reversal/Wink
- Yes
EMC
- EN55022/EN5504 and FCC part 15 Class B
Safety
- UL
Grandstream GXW-4104 Analog FXO Gateway
The Grandstream GXW-4104 series enables businesses of all sizes to create an easy-todeploy VoIP solution. This FXO gateway offers the ability to seamlessly connect multiple locations and all devices within an office to any hosted or on premise IP PBX network to make deployments as easy as possible. The GXW410x series includes 4/8 FXO ports, 2 10/100 Mbps ports and supports SIP video through the H.264 codec. Advanced telephony features, easy automated provisioning and superb voice quality allow the GXW410x series to be the ideal VoIP gateway for businesses.
- 4 ports
- 2 10/100 Mbps network ports
- Comprehensive codec support, caller ID, flexible dial plans and security protection
- Advanced security protection with SRTP
A SIP proxy server such as Asterisk or a SIP registrar server can be deployed with the GXW-4104 series. In this environment, the SIP server handles SIP registration and call control and the GXW-4104 processes media conversion between IP and PSTN calls. By design, the system supports the North American call progress tones and signaling standards on PSTN sides.
Grandstream GXW-4104 Technical SpecificationTelephone Interfaces
- 4RJ11 FXO ports
Network Interfaces
- 10M/100Mbps, dual RJ45 ports
LED indicators
- Power, Network and Line LEDs
Voice-over-Packet Capabilities
- G.168 compiant Echo Cancelation, Dynamic Jitter Buffer, Moderm detection & auto-switch G.711
PTSN Fail-over Life Line
- PTSN failover on power failure
Voice Compression
- G.711, G.723, G.726 (40/32/24/16), G.729A/B/E, G.728, iLBC
DHCP Client
- Yes, Switched Mode or PPPoE
Fax over IP
- T.38 compliant Group 3 Fax Relay up to 14.4kpbs & auto-switch to G.711 for Fax Pass-through
QoS
- Diffserve, TOS, 802.1P/Q VLAN tagging
IP Transport
- RTP/RTCP
DTMF Method
- flexible DTMF transmission method, user interface of in-audio, RFC2833, and/or SIP info
IP Signaling
- SIP (RFC 3261)
SIP Server Profiles & Accounts Per System
- Up to 2 distinct SIP server profiles per system and independent SIP account per port
Provisioning
- TFTP and HTTP
Media
- SRTP
Management
- Syslog support, HTTPS, telnet, remote mamangement using web browser
Power
- Output: 12VDC Input: 100-240VAC / 50-60Hz
Environmental
- Operational: 32-104°F or 0-40°C
- Storage: 14-140°F or -10-60°C
- Humidity: 10-90% Non-condensing
Dimensions (LxWxH)
- 230mm x 135mm x 35mm
Mounting
- Wall mount and desktop
Short & Long Haul
- REN3: Up to 150ft on 24AWG line
Caller ID
- Bellcore Type 1&2, ETSI, BT, NTT, and DTMF-based CID
Polarity Reversal/Wink
- Yes
EMC
- EN55022/EN5504 and FCC part 15 Class B
Safety
- UL
