Ubiquiti UniFi Protect Network Video Recorder Pro (UNVR-Pro)
Ubiquiti UniFi Protect Network Video Recorder Pro (UNVR-Pro)
The Ubiquiti UniFi Protect UNVR-Pro is an enterprise network video recorder that integrates UniFi Protect with a scalable 7-drive bay NVR. It supports up to seven SSD/HDDs in RAID one or RAID five configuration for reliable, worry-free video storage.
UniFi UNVR-Pro Key Features
- Seven 2.5"/3.5" Drive Bays - (1) 10G SFP+ Port
- One Gigabit RJ45 Port - 2U Rackmountable (Kit Included)
- 1.3" Touchscreen with Video Event Preview
- UniFi Protect Integrated with NVR
- Bluetooth for Easy Setup with UniFi Protect Application
- Automated Secure RAID 1/5
- USP-RPS Support for Redundant Power Backup
The UNVR-Pro features a 1.3" touchscreen display that conveniently offers video event preview*. Additional features include 10G SFP+ and Gigabit RJ45 LAN ports for local video access, a 2U rackmountable enclosure, and UniFi SmartPower Redundant Power System (USP-RPS) support to help protect against an internal PSU failure or interruption.
The UNVR-Pro can be managed with UniFi Protect App (available on iOS version 1.4.3 or higher, and Android version 1.3.9 or higher).
General
- Dimensions: 442 x 325 x 87 mm (17.4 x 12.8 x 3.4")
- Weight:
- Without Rackmount Brackets: 9.2 kg (20.28 lb)
- With Rackmount Brackets: 9.45 kg (20.83 lb) - Enclosure Characteristics: SGCC Steel
- Mount Materials: SGCC Steel
- Processor: Quad-Core ARM Cortex-A57 at 1.7 GHz
- System Memory: 4 GB
- On-Board Flash Storage: 32GB
- Max. Power Consumption: 160W
- Max. Power Budget for Drives: 135W
- Power Method:
- 1x Universal AC input, 100-240VAC, 3A Max, 50/60 Hz
- 1x USP-RPS DC input, 11.5VDC, 13.91A - Power Supply: AC/DC, Internal, 200W
- Networking Interfaces:
- 1x 10/100/1000 Mbps RJ45 Ethernet
- 1x 1/10 Gbps SFP+ Ethernet - RF Interface: 1x Bluetooth v4.1
- LCM Display:
- 1 x 1.3" Touchscreen
- Bootup Animation: Bootup in Progress
- Firmware Upgrade Icon: Firmware Upgrading
- Steady White: Factory Defaults, Awaiting Adoption
- Steady Blue: Device is Adopted - Management Interface: Ethernet In-Band Management
- ESD/EMP Protection: Air: ± 12kV, Contact: ± 8kV
- Operating Temperature: -5 to 40° C (23 to 104° F)
- Operating Humidity: 5 - 95% Noncondensing
- LEDs:
- Ethernet: Green: 1000 Mbps, Amber: 10/100 Mbps
- SFP+: White: 10 Gbps, Green: 1 Gbps
- HDD: Amber: Disk Error, White: Disk Detected
- RPS: Bllue: Ready
