AudioCodes MediaPack 204 Analog Telephony Adapter with 4 FXS ports (MP204B/4S/SIP)
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020

AudioCodes MediaPack 204 Analog Telephony Adapter with 4 FXS ports (MP204B/4S/SIP)

Available:In Stock

AudioCodes MediaPack 204 Analog Telephony Adapter with 4 FXS ports (MP204B/4S/SIP)

The AudioCodes MP204B/4S/SIP  is an analog telephone adapter that enables cost-effective and rapid migration of legacy analog telephones, fax machines and conference speakerphones to VoIP services. Their enhanced feature set includes support for multiple lines and optional 3G/4G cellular broadband access.

AudioCodes MP204B/4S/SIP Key Features

  • Wide versatility
  • Enhanced security
  • Fax support
  • Superior quality
  • Easy monitoring
  • SOHO telephony 4 port VoIP gateway for Voice over Broadband (VoBB) networks
  • 3G/4G access support for broadband access (through USB dongle)
  • TR-069 protocol and user-friendly local web wizard for easy remote provisioning
  • Certified for BroadSoft’s BroadWorks and BroadCloud
  • Supports a rich set of subscriber calling features
  • Optional integrated router including firewall and NAT with smart Quality of Service (QoS)
  • Media encryption using Secure Real-Time Transfer Protocol (SRTP)
  • Optional integration of robust, reliable fax over HTTP application including Fax2Email and Email2Fax
  • Optional integrated BroadSoft’s PacketSmart probe
AudioCodes MP204B/4S/SIP Technical Specification

Available Hardware Configurations

  • Access: 1 x 10/100/1000
  • LAN: 1 x 10/100/1000
  • FXS: 4
  • USB 2.0: 1

WAN Access

  • Ethernet WAN: 10/100/1000Mbps Ethernet ports, for connection to xDSL/Cable/xPON modems
  • Ethernet: 3G/4G WAN access through USB dongle (not supplied with the MP-20x, specific dongles supported)

Optional Data Routing and Security

  • Data Protocols:- IPv4, IPV6**, PPPoE, PPPoA, PPTP, DNS proxy, dynamic DNS, DHCP client, server and proxy, IP
    - NAT – RFC3022, Application Layer Gateway (ALG), port triggering, UPnP auto-configuration and port-forwarding (IGD)
  • QoS:
    - IEEE 802.1p/Q (QoS & VLAN tagging)
    - ToS/Diffserv
    - QoS traffic prioritisation and shaping
  • Data Security and Firewall: SPI firewall, URL filtering, advanced access control, denial-of-service prevention, configuration file encryption, web authentication, HTTPS provisioning
  • SIP Security: SIP over TLS 1.2 (SIPS)

Voice over IP

  • Signalling Protocols:
    - SIP over TCP/UDP/TLS – RFC 3261
    - Interoperability with leading softswitches
    - Up to 4 individual SIP accounts
  • Media Processing:
    - Voice codecs G.711μ/a-law, G.729A/B, G.723.1
    - Medi
