Ubiquiti UniFi Switch Enterprise 48 PoE (USW-Enterprise-48-PoE)
- Category:ALL PRODUCTS,Best selling products,Intel: Revolutionizing Computing Technology,New products,Ubiquiti,Ubiquiti Switches
Ubiquiti UniFi Switch Enterprise 48 PoE (USW-Enterprise-48-PoE)
The Ubiquiti UniFi Switch USW-Enterprise-48-PoE is a fully managed, Layer 3 switch with 48 x 2.5GbE RJ45 Ethernet ports with PoE+ for WiFi 6 APs, and four 10GbE SFP+ ports for fiber uplinks.
Ubiquiti UniFi Switch USW-Enterprise-48-PoE key features
- 48 x 2.5GbE 802.3af/at PoE+ RJ45 ports
- 4 x 10GbE SFP+ ports
- USP RPS support for redundant power backup
- 400W total PoE capacity
- 1.3" LCM touchscreen with AR switch management
Mechanical
- Dimensions: 442 x 44 x 399 mm(17.4 x 1.7 x 15.7")
- Weight
- Without Mount: 6.2 kg (13.67 lb)
- With Mount: 6.3 kg (13.89 lb) - Enclosure Material: SGCC Steel
- Mount Material: SGCC Steel
Hardware
- Total Non-Blocking Throughput: 160 Gbps
- Switching Capacity: 320 Gbps
- Forwarding Rate: 238.095 Mpps
- Max. Power Consumption: 100W
- Power Method:
- Universal AC Input: 100-240VAC, 8.5A Max, 50/60 Hz
- USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A - Power Supply: AC/DC, Internal, 100-240V, 8.5A Max
- Management Interface: Ethernet In-Band
- Networking Interfaces: 48 x 100/1000/2500 Mbps RJ45 Ethernet
- SFP+ Interfaces: 4 x 1/10G SFP+
- PoE Interfaces: 48 x PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
- Total available PoE: 400W
- Max. PoE+ Wattage per Port by PSE: 34.2W
- Voltage Range 802.3af Mode: 44 to 57V
- Voltage Range 802.3at Mode: 50 to 57V
- Services: SMB Layer 3 PoE Gigabit Ethernet Switch
- ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
- LCM Display:
- 1.3" Touchscreen
- Bootup Animation: Bootup in Progress
- Firmware Upgrade Icon: Firmware Upgrading
- Steady White: Factory Defaults, Awaiting Adoption
- Steady Blue: Device is Adopted - Button: Factory reset
- Operating Temperature -5 to 40° C (23 to 104° F)
- Operating Humidity 10 - 90% Noncondensing
- Certifications CE, FCC, IC
LED
- Ethernet: White: Link or Activity
- SFP+: White: Link or Activity
Ubiquiti UniFi Switch Enterprise 48 PoE (USW-Enterprise-48-PoE)
The Ubiquiti UniFi Switch USW-Enterprise-48-PoE is a fully managed, Layer 3 switch with 48 x 2.5GbE RJ45 Ethernet ports with PoE+ for WiFi 6 APs, and four 10GbE SFP+ ports for fiber uplinks.
Ubiquiti UniFi Switch USW-Enterprise-48-PoE key features
- 48 x 2.5GbE 802.3af/at PoE+ RJ45 ports
- 4 x 10GbE SFP+ ports
- USP RPS support for redundant power backup
- 400W total PoE capacity
- 1.3" LCM touchscreen with AR switch management
Ubiquiti UniFi Switch USW-Enterprise-48-PoE Technical Specification
Mechanical
- Dimensions: 442 x 44 x 399 mm(17.4 x 1.7 x 15.7")
- Weight
- Without Mount: 6.2 kg (13.67 lb)
- With Mount: 6.3 kg (13.89 lb) - Enclosure Material: SGCC Steel
- Mount Material: SGCC Steel
Hardware
- Total Non-Blocking Throughput: 160 Gbps
- Switching Capacity: 320 Gbps
- Forwarding Rate: 238.095 Mpps
- Max. Power Consumption: 100W
- Power Method:
- Universal AC Input: 100-240VAC, 8.5A Max, 50/60 Hz
- USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A - Power Supply: AC/DC, Internal, 100-240V, 8.5A Max
- Management Interface: Ethernet In-Band
- Networking Interfaces: 48 x 100/1000/2500 Mbps RJ45 Ethernet
- SFP+ Interfaces: 4 x 1/10G SFP+
- PoE Interfaces: 48 x PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
- Total available PoE: 400W
- Max. PoE+ Wattage per Port by PSE: 34.2W
- Voltage Range 802.3af Mode: 44 to 57V
- Voltage Range 802.3at Mode: 50 to 57V
- Services: SMB Layer 3 PoE Gigabit Ethernet Switch
- ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
- LCM Display:
- 1.3" Touchscreen
- Bootup Animation: Bootup in Progress
- Firmware Upgrade Icon: Firmware Upgrading
- Steady White: Factory Defaults, Awaiting Adoption
- Steady Blue: Device is Adopted - Button: Factory reset
- Operating Temperature -5 to 40° C (23 to 104° F)
- Operating Humidity 10 - 90% Noncondensing
- Certifications CE, FCC, IC
LED
- Ethernet: White: Link or Activity
- SFP+: White: Link or Activity
