Ubiquiti UniFi Switch Enterprise 48 PoE (USW-Enterprise-48-PoE)

Available:In Stock
£1,430.40

Ubiquiti UniFi Switch Enterprise 48 PoE (USW-Enterprise-48-PoE)

The Ubiquiti UniFi Switch USW-Enterprise-48-PoE is a fully managed, Layer 3 switch with 48 x 2.5GbE RJ45 Ethernet ports with PoE+ for WiFi 6 APs, and four 10GbE SFP+ ports for fiber uplinks.

Ubiquiti UniFi Switch USW-Enterprise-48-PoE key features

  • 48 x 2.5GbE 802.3af/at PoE+ RJ45 ports
  • 4 x 10GbE SFP+ ports
  • USP RPS support for redundant power backup
  • 400W total PoE capacity
  • 1.3" LCM touchscreen with AR switch management
The USW-Enterprise-48-PoE is a configurable, Layer 3 switch with auto-sensing 802.3at PoE+. It offers 48 x 2.5GbE RJ45 Ethernet ports, and four 10GbE SFP+ ports, providing 2.5GbE PoE links to your WiFi 6 APs and 10GbE fiber uplinks to your network. The USW Enterprise 48 PoE also features a 1.3" LCM touchscreen. Easily managed in the UniFi Network application (web or mobile), the USW Enterprise 48 PoE offers Layer 3 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network application (web or mobile) also allow admins to configure and monitor the USW Enterprise 48 PoE from anywhere via an intuitively designed user interface.


Ubiquiti UniFi Switch USW-Enterprise-48-PoE Technical Specification

Mechanical

  • Dimensions: 442 x 44 x 399 mm(17.4 x 1.7 x 15.7")
  • Weight
    - Without Mount:  6.2 kg (13.67 lb)
    - With Mount: 6.3 kg (13.89 lb)
  • Enclosure Material: SGCC Steel
  • Mount Material: SGCC Steel

Hardware

  • Total Non-Blocking Throughput: 160 Gbps
  • Switching Capacity: 320 Gbps
  • Forwarding Rate: 238.095 Mpps
  • Max. Power Consumption: 100W
  • Power Method:
    - Universal AC Input: 100-240VAC, 8.5A Max, 50/60 Hz
    USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A
  • Power Supply: AC/DC, Internal, 100-240V, 8.5A Max
  • Management Interface: Ethernet In-Band
  • Networking Interfaces: 48 x 100/1000/2500 Mbps RJ45 Ethernet
  • SFP+ Interfaces: 4 x 1/10G SFP+
  • PoE Interfaces: 48 x PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Total available PoE: 400W
  • Max. PoE+ Wattage per Port by PSE: 34.2W
  • Voltage Range 802.3af Mode: 44 to 57V
  • Voltage Range 802.3at Mode: 50 to 57V
  • Services: SMB Layer 3 PoE Gigabit Ethernet Switch
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • LCM Display:
    1.3" Touchscreen
    - Bootup Animation: Bootup in Progress
    - Firmware Upgrade Icon: Firmware Upgrading
    - Steady White: Factory Defaults, Awaiting Adoption
    - Steady Blue: Device is Adopted
  • Button: Factory reset
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 10 - 90% Noncondensing
  • Certifications CE, FCC, IC

LED

  • Ethernet: White: Link or Activity
  • SFP+: White: Link or Activity
