Allrack 12U Data Cabinet (CAB126X8)
![Allrack 12U Data Cabinet (CAB126X8)]()
![Allrack 12U Data Cabinet (CAB126X8)]()
Allrack 12U Data Cabinet (CAB126X8)
Available:Out of Stock
£356.40
Please Note: For an available alternative, please see the CAB186X8.
Allrack 12U Data Cabinet (CAB126X8)
The AllrackCAB126X8 is high quality and cost effective 19-inch rack for comms rooms and other infrastructure deployments. All doors and panels are lockable and removable giving all round access. The fully adjustable 19" mounting profiles are printed numerically with the "U" height, for ease of installation and future use. Cable entry is from directly underneath or in the back of the roof using cable entry glands.
Allrack CAB126X8 Key Features
12U (HxWxD) 716mm x 600mm x 800mm.
Heavy-duty 19-inch steel mounting profiles.
Steel framed/toughened glass front door.
Lockable front door, read door and side panels.
Vented roof panel for additional air flow.
Smooth black RAL9005 powder coated paint finish.
Delivered assembled as standard (Flat-packed optional).
Allrack CAB126X8 Technical Specifications
Description
Industry standard design 19” floor data cabinets.
Material
Cold rolled steel construction for cabinet frame, toughened glass panel insert in steel framework for front door.
Finish
Smooth black RAL9005 powder coated paint finish.
Racks
Supplied with depth adjustable heavy-duty steel mounting profiles to take industry standard 19’’ patch panels and equipment. All 800 wide cabinets come complete with side vertical management as standard.
Doors
Steel framed / toughened glass front door
Steel rear door
Steel side panels
All lockable and removable
Locks
Lockable front door
Lockable rear door
Lock and slam locks on side panels
Ventilation
Through roof panel and via fan tray.
Options
Delivered assembled as standard. Flat-packed optional.
Additional Accessories (not included)
Fan trays (roof/rack mount). Plinth kits. Shelves (fixed / telescopic). Heavy duty castors. Levelling feet. Baying kits. Earth bonding kits. Cable tray
Profile Distances
The mounting profiles can be adjusted forwards and backwards to utilise almost the full depth of the cabinets.
Static Loading
600kg
