CyberData SIP Loudspeaker Amplifier AC Powered (011404)
- Category:Best selling products,New products
CyberData SIP Loudspeaker Amplifier AC Powered (011404)
The CyberData SIP-enabled Loudspeaker Amplifier (011404) provides an easy method for implementing a loud IP-based overhead paging system for loud areas, warehouses, manufacturing areas, and outdoor areas.
CyberData 011404 Key Features
- SIP Enhanced interoperability for hosted environments
CyberData has maintained one of the most comprehensive list of IP PBX servers certified to work with CyberData - Security Features:
Support for security code access for SIP paging
Autoprovisioning via HTTPS
HTTPS web based configuration - Support for G.722 codecs
- 802.11q VLAN tagging
- Configurable sense input for use with fault detection
- Configurable event generation for device health and status monitoring
- Optional direct connect RGB strobe kit connection
- 9 user-uploadable page messages
With up to 9 user-stored messages, the Amplifier provides direct drive of up two 8 Ohm horns. The interface is compatible with most SIP-based IP PBX servers that comply with the SIP RFC 3261. For non-SIP environments, the Loudspeaker Amplifier can be configured to listen to multicast address and port number combinations to form paging zones.
Features
- Packaged in a NEMA 3R/IP42-rated enclosure SIP and Simultaneous Multicast
- Dual-speed ethernet 10/100 Mbps
- Web-based configuration
- PoE 802.3at and 802.3af-enabled Line-in for background music
- Line-out connector
- DTMF controlled relay
- Direct 8 Ohm speaker drive
- User-uploadable tones and messages
- Digital and manual volume control
- Second SIP endpoint "Night Ringer"
- Autoprovisioning
- Auto-call voice message from input port sense Can support two horns
- HTTP Command Interface
- 10 channel prioritized Multicast ports
- Built-in diagnostics
- Delayed page support
- Cisco SRST
General
- Ethernet I/F 10/100 Mbps
Protocol SIP RFC 3261 Compatible
Power Input PoE 802.3at or 802.3af
Audio Output 802.3at - SPL 117 dB @ 1 meter
(When used with the 011068 Mini Horn.) - Line Out:
Output Signal Amplitudes 2.0 VPP maximum
Output Level +2dBm nominal
Total Harmonic Distortion 0.5% maximum
Output Impedance 10k ohm - Operating Temperature -10 degrees C to 50 degrees C (14 degrees F to 122 degrees F)
- Payload Types G.711 μ-law, G.711 a-law, and G.722 + Singlewire HD
- Dimensions
10 in. [254 mm] Length
4 in. [101.6 mm] Width
14 in. [355.6 mm] Height - Boxed Weight 6.5 lbs. [2.95 kg]
- Warranty 2 Years Limited
- Part Number 011404
- Loudspeaker Part Number 011068
