Dinstar DAG1000-8O 4*FXO+ 4*FXS Gateway (DAG1000-4S4O)

£240.96

The Dinstar DAG1000‑4S4O Hybrid Analog VoIP Gateway (4 FXS + 4 FXO) offers seamless connectivity between IP telephony and legacy analog phones, fax machines, and PSTN lines. With failover resilience, SIP compatibility, T.38 fax support, and robust routing, it’s ideal for SMBs, call centers, and branch offices seeking efficient analog-to-VoIP integration

Add to WishlistCompare

apple paygoogle payjcbmasterpaypalvisa
Ask a Question
Vendor: Dinstar
SKU: DAG1000-4S4O
Availability: In Stock Pre order Out of stock
Description

Dinstar DAG1000-8O 4*FXO+ 4*FXS Gateway (DAG1000-4S4O)

The DAG1000-4S4O Hybrid Analog VoIP Gateway offering seamless connectivity between IP-based telephony networks and legacy telephones (POTS), fax machines and PBX systems. The analog gateway has 4 FXS and 4 FXO ports which integrates both FXS and FXO features. Besides, the gateway is also designed with power failover and IP/SIP fail over features. With the standard SIP protocol, it's compatible with leading IMS/NGN platforms and SIP-based IP Phone systems. It provides low-cost and easy-to-use VoIP solutions for small and medium businesses, call centers, SOHO, remote offices as well as enterprises with multiple branches.

Dinstar DAG1000-4S4O Key Features

    • 4 FXS and FXO hybrid
    • Flexible port group
    • IP trunk
    • Flexible routing and manipulation
    • Data/ Voice/ Management VLAN
    • Voice and FAX all in one
    • Power and network failure life line
    • Firmware update automatically/configure update
      Dinstar DAG1000-4S4O - Technical Specifications

      Physical Interfaces

      • Phone Interfaces: 4FXS and 4FXO, RJ-11
      • Ethernet Interfaces: 4*RJ-45 10/100Base-Tx, RJ-45
      Voice & Fax
      • Protocol: SIPv2, SDP, RTP (RFC2833)
      • Codecs: G.711A/U law, G.723.1, G.729A/B
      • Echo Cancellation: G.168 with up to 128ms
      • FAX: T.38, Pass-through
      • DTMF: Signal, RFC2833, INBAND
      • NAT Traversal: STUN, Dynamic/Static NAT
      • QoS: VLAN 802.1P/Q, DIFFServ ToS

      FXO Port

      • Dialing Modes: Pulse and DTMF
      • Pulse Dialing: 10 and 20 PPS
      • Caller ID: DTMF, Bellcore Type 1&2, ETSI, BT, NTT
      • Busy Tone/No Current Detection, Polarity Reversal Detection
      • Lifeline: Power/Network Failure Lifeline

      FXS Port

      • Dialing Modes: Pulse and DTMF
      • Caller ID: DTMF and FSK Presentation
      • Hook Flash: Local or Relay processing
      • Polarity Reversal: for Call Connect / Disconnection Signaling

      Supplement Services

      • Call Waiting
      •  Call Transfer (Blind transfer, Attendant Transfer)
      • Call Forwarding
      • Hotline
      • Call Hold
      • Do-not-disturb

      Power Supply

      • Input: 12VDC 2A, Power Adapter
      • Power Consumption (Typical): 20W

      Other

      • Dimension: 242(L) * 152(W) * 40(H) mm
      • Weight: 1.0KG
      • Operation: -10 °C ~ 45 °C
      • Storage: -20 °C ~ 80 °C
      • Humidity: 10% - 90% Non-condensation
