QuWireless Antenna QuSpot for Teltonika RUTX50

£224.66

QuWireless QuSpot for Teltonika RUTX50

The QuWireless QuSpot for Teltonika RUTX50 is a specially crafted outdoor antenna, meticulously engineered to deliver steadfast wireless connectivity across diverse settings. This comprehensive solution effortlessly combines high-gain omnidirectional 5G and Wi-Fi antennas with the RUTX50, all housed within a single IP67 enclosure. This unified design facilitates the deployment of innovative outdoor RUTX50 solutions.

QuSpot for Teltonika RUTX50 Key Features

  • Outdoor antenna works in any weather conditions, IP67
  • Antenna perfectly matched with the router
  • Passive poe support

Designed for dynamic scenarios, the QuSpot for RUTX50 is an optimal choice for outdoor wireless connectivity in mobile applications such as transportation, yachting, boats, camping, and even urban centres characterised by high signal density.

QuSpot for Teltonika RUTX50 - Technical Specifications

FREQUENCY

  • 617 - 960 MHz
  • 1.7 - 2.7 GHz
  • 3.3 - 4.3 GHz

SUPPORTED LTE BANDS

  • 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 1067, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, n77, n78, n80, n81, n82, n83, n84, n86, n89, n90, n95, n97, n98, n100, n101

SUPPORTED 5G BANDS

  • n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256

GAIN

  • 617 - 960 MHz : 2 dBi
  • 1.7 - 2.7 GHz : 4 dBi
  • 3.3 - 4.3 GHz : 4.5 dBi

VSWR

  • <2.00, max <2.50

BEAMWIDTH

  • 360°/25° ±5°

POLARISATION

  • Vertical

IMPEDANCE

  • 50 Ω
Add to WishlistCompare

apple paygoogle payjcbmasterpaypalvisa
Ask a Question
Vendor: QuWireless
SKU:
Availability: In Stock Pre order Out of stock
Description

QuWireless QuSpot for Teltonika RUTX50

The QuWireless QuSpot for Teltonika RUTX50 is a specially crafted outdoor antenna, meticulously engineered to deliver steadfast wireless connectivity across diverse settings. This comprehensive solution effortlessly combines high-gain omnidirectional 5G and Wi-Fi antennas with the RUTX50, all housed within a single IP67 enclosure. This unified design facilitates the deployment of innovative outdoor RUTX50 solutions.

QuSpot for Teltonika RUTX50 Key Features

  • Outdoor antenna works in any weather conditions, IP67
  • Antenna perfectly matched with the router
  • Passive poe support

Designed for dynamic scenarios, the QuSpot for RUTX50 is an optimal choice for outdoor wireless connectivity in mobile applications such as transportation, yachting, boats, camping, and even urban centres characterised by high signal density.

QuSpot for Teltonika RUTX50 - Technical Specifications

FREQUENCY

  • 617 - 960 MHz
  • 1.7 - 2.7 GHz
  • 3.3 - 4.3 GHz

SUPPORTED LTE BANDS

  • 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 1067, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, n77, n78, n80, n81, n82, n83, n84, n86, n89, n90, n95, n97, n98, n100, n101

SUPPORTED 5G BANDS

  • n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256

GAIN

  • 617 - 960 MHz : 2 dBi
  • 1.7 - 2.7 GHz : 4 dBi
  • 3.3 - 4.3 GHz : 4.5 dBi

VSWR

  • <2.00, max <2.50

BEAMWIDTH

  • 360°/25° ±5°

POLARISATION

  • Vertical

IMPEDANCE

  • 50 Ω
