Ubiquiti UniFI 7 Long-Range Access Point (U7-LR)
The Ubiquiti UniFi 7 Long-Range Access Point is a high-performance Wi-Fi 7 access point designed for extended coverage and capacity. It features tri-band connectivity (2.4 GHz, 5 GHz, and 6 GHz) with 2x2 MU-MIMO on each band, supporting up to 300+ concurrent clients. The device offers a maximum throughput of 688 Mbps on 2.4 GHz, 4.3 Gbps on 5 GHz, and 5.8 Gbps on 6 GHz bands. With a 2.5 GbE uplink and PoE+ support, it's suitable for high-density environments requiring robust wireless performance.
Ubiquiti UniFi 7 Long-Range Access Point Key Features:
- Tri-Band Wi-Fi 7 (802.11be): Operates on 2.4 GHz, 5 GHz, and 6 GHz bands, supporting wider channels up to 320 MHz for increased throughput.
- 2x2 MU-MIMO on Each Band: Facilitates simultaneous communication with multiple devices, enhancing network efficiency.
- High Throughput Rates: 2.4 GHz: Up to 688 Mbps, 5 GHz: Up to 2.9 Gbps, 6 GHz: Up to 5.8 Gbps
- 2.5 GbE Uplink Port: Provides a high-speed wired connection to support the increased wireless throughput.
- PoE+ Support: Simplifies installation by delivering both data and power over a single Ethernet cable.
- Coverage Area: Designed to cover up to 140 m² (1,500 ft²), making it suitable for large spaces.
- Concurrent Client Capacity: Supports over 300 concurrent clients, ideal for high-density environments.
- Advanced Wi-Fi Features: Includes OFDMA, 4096-QAM modulation, and enhanced MU-MIMO for improved performance and efficiency.
- Seamless Integration: Compatible with UniFi Network Controller for centralized management and monitoring.
Ubiquiti UniFi 7 Long-Range Access Point - Technical Specifications
Overview
- Dimensions: Ø171.5 x 33 mm (Ø6.8 x 1.3")
- WiFi Standard: WIFi 7
- Spatial Streams: 5
- Coverage Area: 160 m² (1,750 ft²)
- Max. Client Count: 300+
- Uplink: 2.5 GbE
- Mounting Locations: Ceiling, wall
- Mounting Plate: Plastic mounting plate (Included)
- Power Method: PoE
Performance
- MIMO 5 GHz 3 x 3 (DL/UL MU-MIMO)
- 2.4 GHz 2 x 2 (DL/UL MU-MIMO)
- Max. Data Rate
- 5 GHz 4.3 Gbps (BW240)
- 2.4 GHz 688 Mbps (BW40)
- Antenna Gain 5 GHz 6 dBi
- 2.4 GHz 4 dBi
- Max. TX Power 5 GHz 27 dBm 2.4 GHz 26 dBm
- Supported Data Rates 802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3, EHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 3.6 Gbps (MCS0 - MCS11 NSS1/2/3, HE 20/40/80/160) 802.11ac (WiFi 5) 6.5 Mbps to 2.6 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80/160) 802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23 , HT 20/40)
Features
- Wireless Meshing: Yes
- Band Steering: Yes
- 802.11v BSS Transition Management: Yes
- 802.11r Fast Roaming: Yes
- 802.11k Radio Resource Management (RRM): Yes
- Advanced Radio Management: Yes
- Passpoint (Hotspot 2.0): Yes
- Captive Hotspot Portal
- Custom Branding Landing Page: Yes
- Voucher Authentication: Yes
- Payment-Based Authentication: Yes
- External Portal Server Support: Yes
- Password Authentication: Yes
- Guest Network Isolation: Yes
- Private Pre-Shared Key (PPSK): Yes
- WiFi Speed Limiting: Yes
- Client Device Isolation: Yes
- WiFi Schedules: Yes
- RADIUS over TLS (RadSec): Yes
- Dynamic RADIUS-assigned VLAN: Yes
Hardware
- Max. Power Consumption: 14W
- Includes PoE Adapter —
- Supported Voltage Range: 42.5—57V DC
- Networking Interface: (1) 2.5 GbE RJ45 port
- Weight: 448 g (15.8 oz)
- Management: Ethernet
- Enclosure Material: Polycarbonate, aluminum alloy
- Mount Material: Polycarbonate, galvanized steel (SGCC)
- LEDs System - White/Blue
- Channel Bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160 (MHz)
- Certifications: CE, FCC, IC
- NDAA Compliant - ✓
- Ambient Operating Temperature: -30 to 40° C (-22 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
Software
- Application Requirements
- UniFi Network
- Version 9.0.114 and later
- UniFi OS
- iOS™ version 10.20.2 and later, Android™ version 10.21.7 and later
Download
Download File
Additional Information
| Integrated PoE |
Yes |
|---|
